Description
| Model | Description | Conductor O.D (mm) | Isulation (mm) | Shielding (V) | Jacket O.D(mm) |
| NC5E-U10 | Cat5e UTP 0.51mm 4 Pairs 10% Cu 24 AWG Length: 305m/roll - White | 0.51 CCA | PE 0.91 | Yes | PVC 5.1 |
| NC5E-F10 | Cat5e FTP 0.51mm 4 Pairs anti-jamming 10% Cu 24 AWG Length: 305m/roll - Blue / White | 0.51 CCA | PE 1.00 | Yes | PVC 5.1 |
| NC5E-F100 | Cat5e FTP 0.51mm 4 Pairs anti-jamming 100% Cu 24 AWG Length: 305 m/roll - Blue / White | 0.56 BC | PE 1.00 | Yes | PVC 5.1 |
| NC5E-F100P | Cat5e FTP 0.51mm 4 Pairs anti-jamming 100% Cu 24 AWG - Pass fluke test Length: 305m/roll- Gray | 0.56 BC | PE 1.00 | Yes | PVC 5.1 |
| NC5E-F100 O | Cat5e FTP 0.51mm 4 Pairs anti-jamming have oil 100% Cu 24 AWG Length: 305m/roll - Blue / White | 0.56 BC | PE 1.00 | Yes | PVC 5.1 |
| NC6-U10 | CAT6 UTP 0.56 mm 4 Pairs 10% Cu 23 AWG Length: 305m/roll - White | 0.56 CCA | PE 1.02 | Yes | PVC 6.0 |
| NC6-F10 | CAT6 FTP 0.56 mm 4 Pairs anti-jamming 10% Cu 23 AWG Length: 305m/roll - Blue / White | 0.56 CCA | PE 1.00 | Yes | PVC 6.6 |
| NC6-F100 | CAT6 FTP 0.56mm 4 Pairs anti-jamming, 100% Cu 23 AWG Length: 305m/roll - Blue / White | 0.56 BC | PE 1.00 | Yes | PVC 6.6 |
| NC6-F100P | CAT6 FTP 0.56mm 4 Pairs anti-jamming, 100% Cu 23 AWG - Pass fluke test Length: 305m/roll - Gray | 0.56 BC | PE 1.00 | Yes | PVC 6.6 |
| NC6-F100 O | CAT6 FTP 0.56mm 4 Pairs anti-jamming, have oil 100% Cu 23 AWG Length: 305m/roll - Blue / White | 0.56 BC | PE 1.00 | Yes | PVC 6.6 |
